Hiltra
Labsaver F90 LS1220-EN gray (B-choice)
| Model specifications | |
|---|---|
| Article number | 120600200-B |
| Delivery time | Direct from stock ! |
| B-choice | This is a factory-new safety cabinet with minor warehouse damage such as light scratches in the paint finish or small dents in the housing, for example |
| Certification | F90 in accordance with EN 14470-1 / EN 14727 / GS |
| External dimensions WxDxH | approx. 1200 x 600 x 2035 mm |
| Internal dimensions WxDxH | approx. 1095 x 450 x 1824 mm |
| Internal height from the drip tray | approx. 1724 mm |
| Door | Double |
| Furnishing | 3x adjustable shelf, 1x bottom tray incl. insert grid |
| Shelf BxDxH | approx. 1070 x 425 x 30 mm |
| Bottom drip tray WxDxH | approx. 1093 x 440 x 80/100 mm |
| Carrying capacity of shelves and bottom drip tray | 75 kg with evenly distributed load |
| Shelf distribution (standard) | approx. 500, 900, 1300 mm above the bottom drip pan |
| Collection capacity bottom leakage bin | approx. 37.75 liters (max permitted packaging: 34.3 liters) |
| Own weight | approx. 375 kg |
| Packaging, transportation | on pallet, upright H=2200 mm |
| Article number | 120600200-B |
| Delivery time | Direct from stock ! |
| B-choice | This is a factory-new safety cabinet with minor warehouse damage such as light scratches in the paint finish or small dents in the housing, for example |
| Certification | F90 in accordance with EN 14470-1 / EN 14727 / GS |
| External dimensions WxDxH | approx. 1200 x 600 x 2035 mm |
| Internal dimensions WxDxH | approx. 1095 x 450 x 1824 mm |
| Internal height from the drip tray | approx. 1724 mm |
| Door | Double |
| Furnishing | 3x adjustable shelf, 1x bottom tray incl. insert grid |
| Shelf BxDxH | approx. 1070 x 425 x 30 mm |
| Bottom drip tray WxDxH | approx. 1093 x 440 x 80/100 mm |
| Carrying capacity of shelves and bottom drip tray | 75 kg with evenly distributed load |
| Shelf distribution (standard) | approx. 500, 900, 1300 mm above the bottom drip pan |
| Collection capacity bottom leakage bin | approx. 37.75 liters (max permitted packaging: 34.3 liters) |
| Own weight | approx. 375 kg |
| Packaging, transportation | on pallet, upright H=2200 mm |
| Options and accessories | ||
|---|---|---|
| Flat shelf (extra) for LS1220 RAL7035/grey | 120600208 | € 60,00 |
| Reinforcement profiles for shelf (loadable up to 110 kg) | 120600206 | € 26,00 |
| Drip tray steel H= 80 mm RAL7035 gray for LS1220 | 120600203 | € 47,00 |
| Top-mounted drip tray HDPE LxWxH; 1060x420x50/6 mm for LS1220 | 120600212 | € 177,00 |
| Potential-free grounding inside fixtures | 120600218 | € 77,00 |
| SWD Fan ENG 1-1.6 230V 0.2A 24W IP20, steel | 190170400 | € 252,00 |
| SWD fan ENG 1-1,6 230V 0,2A 24W IP20, stainless steel | 190170601 | € 368,00 |
| Atex fan ENG 2-2.5 230V 1.07A 120W IP55, steel | 190170500 | € 1.036,00 |
| Atex fan ENG 2-2.5 230V 1.07A 120W IP55, stainless steel | 190170600 | € 1.295,00 |
| SWD Motor protection switch 0.16A-0.25A, loose | 820300104 | € 127,00 |
| ATEX Motor Circuit Breaker 1.0A-1.6A, loose | 820300105 | € 1.230,00 |
| SWD Work switch 3p 16A, loose | 190170402 | € 79,00 |
| ATEX Work switch 3p 16A, loose | 190170502 | € 628,00 |
| Flat shelf (extra) for LS1220 RAL7035/grey | 120600208 | € 60,00 |
| Reinforcement profiles for shelf (loadable up to 110 kg) | 120600206 | € 26,00 |
| Drip tray steel H= 80 mm RAL7035 gray for LS1220 | 120600203 | € 47,00 |
| Top-mounted drip tray HDPE LxWxH; 1060x420x50/6 mm for LS1220 | 120600212 | € 177,00 |
| Potential-free grounding inside fixtures | 120600218 | € 77,00 |
| SWD Fan ENG 1-1.6 230V 0.2A 24W IP20, steel | 190170400 | € 252,00 |
| SWD fan ENG 1-1,6 230V 0,2A 24W IP20, stainless steel | 190170601 | € 368,00 |
| Atex fan ENG 2-2.5 230V 1.07A 120W IP55, steel | 190170500 | € 1.036,00 |
| Atex fan ENG 2-2.5 230V 1.07A 120W IP55, stainless steel | 190170600 | € 1.295,00 |
| SWD Motor protection switch 0.16A-0.25A, loose | 820300104 | € 127,00 |
| ATEX Motor Circuit Breaker 1.0A-1.6A, loose | 820300105 | € 1.230,00 |
| SWD Work switch 3p 16A, loose | 190170402 | € 79,00 |
| ATEX Work switch 3p 16A, loose | 190170502 | € 628,00 |
